| Applicable fluid | Air · Non-corrosive gas |
|---|---|
| Repeatability | ±0.1% of full scale (within ±2 digits) |
| Detection pressure accuracy | ±1%F.S. ±1 digit (at an ambient temperature of 25±3℃) |
| Power supply voltage | 12~24V, DC ±10%, fluctuation P-P less than 10% |
| Output action | Select between normally open and normally closed using key operation |
| Output mode | Simple mode/Hysteresis mode/Window comparison mode |
| Protective structure | IP40(IEC) |
| Connection method | Connector connection |
| Connection diameter | M5 internal thread + R(PT)1/8 external thread |
