Valve type and operation mode
|
Direct-acting globe valve
|
|---|---|
|
Operating Fluid
|
Operating Fluid，vacuum [Note 1] |
|
Maximum operating pressure
|
0.7Mpa |
|
Minimum operating pressure
|
Low vacuum ：-0.1Mpa
|
|
Pressure resistance
|
1.05Mpa （ Low vacuum ：-0.1Mpa）
|
|
Fluid temperature
|
5～60°C |
|
Protection class
|
Dustproof
|
|
Shock resistance
|
Below 300m/s2以下
|
|
Environment
|
Cannot be used in corrosive gas environments
|
